  • Research article
  • Open Access

Chitosan-coated sour cherry kernel shell beads: an adsorbent for removal of Cr(VI) from acidic solutions

Journal of Analytical Science and Technology201910:14

https://doi.org/10.1186/s40543-019-0172-6

  • Received: 24 August 2018
  • Accepted: 11 March 2019
  • Published:

Abstract

In this study, a composite biosorbent in the form of beads was produced from chitosan and the powder of sour cherry kernel shells. Characterization of chitosan-coated sour cherry kernel shell beads was done using elemental analysis, FT-IR spectroscopy, SEM, and EDX spectrum analysis. Adsorption capacity of chitosan-coated sour cherry kernel shell beads was tested in removal of Cr(VI) under different conditions, pH 2.0–7.0, adsorbent dosage 0.01–0.20 g, initial Cr(VI) ion concentration 10–315 mg L−1, temperature 25–55 °C, and contact time 0–240 min, and compared to that of uncoated sour cherry kernel shell powder. Cr(VI) adsorption was highly dependent on the solution pH, and the maximum Cr(VI) adsorption was achieved at pH 2.03 at 25 °C in 45 min. The adsorption data was applied to Langmuir, Freundlich, Scatchard, and Dubinin-Radushkevich (D-R) adsorption isotherm models. According to the Langmuir isotherm model, the adsorption capacity of chitosan-coated sour cherry kernel shell beads was found higher than that of uncoated sour cherry kernel shell powder, 24.492 and 13.57 mg g− 1. The study demonstrated that chitosan-coated sour cherry kernel shell beads can be used for Cr(VI) removal from acidic aqueous solutions.

Graphical Abstract image

Graphical abstract

Keywords

  • Adsorption
  • Sour cherry kernel shell
  • Chitosan
  • Cr(VI)
  • Isotherms

Introduction

Designing adsorbents from low-cost and abundant biological waste materials has attracted attention in recent years (Mohan and Pittman Jr 2006). Biomass waste from plants or animals has been widely used to produce environmentally friendly adsorbents. Biopolymers are considered to be an abundant, renewable, biodegradable, and low-cost source of material for the production of adsorbents. These properties make adsorbents with biological origins much more attractive than synthetic adsorbents (Wang and Chen 2009).

Chitin is an excellent structural biopolymer. Chitin is found in many organisms including insects, mushrooms, and arthropods (Kaya et al. 2013). Chitin is easily obtained from, for example, waste of crabs in food processing industry using simple acidic, alkaline, and depigmentation treatments. Then, it is converted into chitosan, a more versatile derivative, through deacetylation procedure under hot alkaline conditions. In deacetylation treatment, free pendant amino groups are formed on the polymeric backbone of chitosan (Ali 2010). These free amino groups make chitosan soluble in acidic solutions and suitable for further modifications. Compared to chitin, chitosan has wider applications due to its gel-forming nature, solubility, and affinity for metal ions (Miretzky and Cirelli 2009, Wu et al. 2010).

Amino and hydroxyl groups are responsible for the affinity of chitosan for metal ions. Protonation of –NH2 and –OH groups enhances the electrostatic interaction of chitosan with negatively charged species (Gupta and Balomajumder 2015). Chitosan in gel form is soluble in acidic environments. It should be stabilized when used in acidic aqueous solutions. Free amino groups of chitosan also enable cross-linking of the polymeric backbone of chitosan. Free amino groups react readily with carbonyl groups of aldehydes. Glutaraldehyde is widely used as a cross-linking agent for chitosan. In the cross-linking procedure, carbonyl groups of glutaraldehyde form Schiff bases with amino functional groups of chitosan. Once cross-linked, chitosan is no longer soluble and can be used in acidic or alkaline aqueous solutions. Through cross-linking procedure, chitosan gel can be used to immobilize micro-sized particles (Sargin and Arslan 2015).

Hexavalent chromium, Cr(VI), is a highly toxic pollutant occurring in the effluents of a number of industries including mining, electroplating, tanning, and fertilizer (Nyangababo et al. 2005). Since it is capable of bio-accumulating in the body especially in the liver, stomach, and kidneys, its removal from the aquatic environment is of utmost importance (Moon et al. 2009, Elwakeel et al. 2018). Cr(VI) is found in aqueous solutions as anions in forms of CrO42−, Cr2O72−, and HCrO4 (Chen et al. 2010), and these anions are cited as mutagenic and carcinogenic at concentrations higher than 0.05 mg L−1 (Gupta and Balomajumder 2015).

Fruit stones are considered as a major source of biomass (Lussier et al. 1994). Stones of many fruits including cherry, date, olive, apricot, and peach are a major source of biomass in the food industry. Fruit stones are widely used in the production of activated carbon (Lussier et al. 1994; Fadhil and Deyab 2008) and adsorbents for the removal of heavy metal pollutants (Strelko Jr et al. 2002, Ahmed and Theydan 2012).

Sour cherry cultivation is very common in Konya, Turkey. Therefore, there are many juice factories using sour cherries for the production of fruit juice. In the literature, there is no report on the use of sour cherry kernel shells for removal of heavy metals. This low-cost waste from the beverage industry can be used as an environmentally friendly adsorbent for heavy metal removal. Using a simple modification, this waste biomass can be used with chitosan to produce microcapsules (composite beads). Immobilization of sour cherry stone powder in chitosan beads can enhance its adsorption capacity and can also make the use of sour cherry stones in sorption studies possible.

In this study, a new adsorbent was prepared from the powder of sour cherry stones and chitosan. Chitosan was used to immobilize the powder of sour cherry kernel shell and to enhance the affinity of shell powder entrapped in the chitosan polymeric matrice for Cr(VI) ions. Adsorptive behavior of the chitosan-coated sour cherry stone shell was tested in the removal of Cr(VI).

Materials and methods

Materials

Chemicals used in this study were of analytical grade. Medium molecular weight chitosan in powder form, K2Cr2O7, and NaOH were purchased from Sigma-Aldrich. Glutaraldehyde, 25% aqueous solution, acetic acid, and HCl were obtained from Merck. Methanol and ethanol were from AnalaR Normapur. Stock solution of Cr(VI) was prepared from K2Cr2O7. Aqueous acetic acid solution was used to dissolve chitosan powder. Alkaline methanol solution was used as a coagulation media. Glutaraldehyde in methanol was used as a cross-linking agent. Sour cherries were obtained from a local market in Konya, Turkey.

Preparation of chitosan-coated sour cherry kernel shells

After removing the flesh of sour cherry fruits, sour cherry stones were washed and the kernels were removed. Then, hard shells were dried at 60 °C in an oven for 24 h. Dried shells were ground and sieved with a 125-μ size sieve. Shell powder was rested in 0.1 M HCl solution, washed extensively with distilled water to neutrality, and then dried at room temperature. This kernel shell powder was called as raw sour cherry kernel shell (R-SCKS).

Chitosan solution was prepared by dissolving 1.0 g of chitosan in 50 mL of acetic acid solution (2% by volume). Following the addition of 0.5 g of shell powder, the chitosan solution was stirred for 2 h to achieve a complete dispersion of shell particles in the solution. Chitosan-shell mixture was transferred into a burette and dropped into a coagulation solution (a solution of 30 g of NaOH, 100 mL of distilled water, and 150 mL of methanol) (Sargın and Arslan 2015). To ensure a complete coagulation, chitosan-shell powder beads (C-SCKS) were rested in the coagulation solution for 24 h. C-SCKS beads were then collected and washed with distilled water to neutrality. Wet C-SCKS beads were treated with glutaraldehyde solution (0.3 mL of glutaraldehyde in 30 mL of methanol) to cross-link chitosan chains (otherwise, uncross-linked polymer would be soluble in acidic solutions) and to provide additional adsorption sites on the beads. In the cross-linking treatment, C-SCKS beads were heated at 70 °C under reflux for 6 h. Finally, cross-linked C-SCKS beads were recovered by filtration and washed with ethanol and distilled water to rid of any unreacted glutaraldehyde molecules. Cross-linked C-SCKS beads were dried at room temperature prior to use.

The adsorbents C-SCKS beads and R-SCKS were characterized through structural, elemental, FT-IR, and SEM-EDX analyses. Elemental analysis was done on a Perkin Elmer Elemental Analyser Model 240 (TUBITAK-Ankara Test and Analysis Laboratory). Structural analysis was performed according to the method reported elsewhere (Li et al. 2004).

Batch Cr(VI) adsorption experiments

A stock solution of Cr(VI) was prepared by dissolving K2Cr2O7 in deionized water. Cr(VI) solutions were prepared by dilution of this stock solution. For pH adjustments, 0.1 M HCl and 0.1 M NaOH solution were used. pH measurements were done on an Orion 900 S2 pH meter.

In adsorption studies, two types of adsorbents were used: composite chitosan-coated kernel shells (C-SCKS beads) and uncoated kernel shell powder (R-SCKS). Their adsorptive behavior was tested in the removal of Cr(VI) ions from aqueous solutions. In Cr(VI) adsorption studies, five parameters were studied: pH (2.0–7.0), adsorbent dosage (0.01–0.20 g), initial metal ion concentration (10–315 mg/L), temperature (25–55 °C) and contact time (0–240 min). pH of the solution was varied in the range of pH 2.0–7.0. Test studies showed that Cr(VI) adsorption was highly dependent on the solution pH.

In adsorption studies, kernel shell powder (R-SCKS, 0.1 g) and chitosan-coated kernel shell powder (C-SCKS, 0.05 g) were added into Cr(VI) solutions (10 mL, 55 mg/L at pH 2.0). The adsorbent-metal systems were stirred on magnetic stirrers at 200 rpm for 2 h. Then, the used adsorbents were filtered with a filter paper and Cr(VI) ion concentration of the filtrate was determined on a UV-visible spectrophotometer (Shimadzu UV-1700). Absorbance measurements were done in the range of 200–600 nm and the maximum absorbance for Cr(VI) ions was recorded at 540 nm.

The equilibrium adsorption capacity of Cr(VI) (qe) (mmol g−1) was calculated using the following equation:
$$ {q}_e=\frac{\left({C}_i-{C}_e\right)V}{W} $$
(1)
where Ci and Ce are the initial and equilibrium concentrations of Cr(VI) in mmol L−1, V is the volume of aqueous solution of Cr(VI) (L), and W is the mass of adsorbents R-SCKS or C-SCKS (g).

Results and discussion

Characterization of the adsorbents

The chemical composition of the adsorbents (chitosan-coated kernel shell powder (C-SCKS) beads and uncoated kernel shell powder (R-SCKS)) was investigated through structural and elemental analyses, FT-IR spectroscopy, SEM micrograph, and EDX spectra. The results of the structural and elemental analyses are presented in Table 1. FT-IR spectra of R-SCKS, C-SCKS, and C-SCKS-Cr(VI) are presented in Fig. 1.
Table 1

The results of structural and elemental analyses of sour cherry kernel shell powder (R-SCKS) and chitosan-coated sour cherry kernel shell powder beads (C-SCKS)

Adsorbents

R-SCKS

C-SCKS

Structural analysis (on basis of dry weight %)

 Ash

1.490

 Extractive

6.98

 Hemicellulose

36.65

 Lignin

37.2

 Cellulose

17.68

Elemental analysis (%)

 Cx

47.95

42.88

 Hx

6.29

5.95

 Ox

44.65

48.22

 Nx

1.11

2.95

XDry and no ash (at 900 °C)

Fig. 1
Fig. 1

FT-IR spectra of sour cherry kernel shell powder (R-SCKS, green), chitosan-coated sour cherry kernel shell powder beads (C-SCKS, red), and C-SCKS-Cr(VI) (blue)

As listed in Table 1, C-SCKS adsorbent had higher oxygen and nitrogen content when compared to R-SCKS. This can be attributed to oxygen- and nitrogen-containing functional moieties of chitosan: OH, –NH2, –CO.

As seen in Fig. 1, major vibration bands on chitosan and sour cherry kernel shell were present after mixing both components together. Following the interaction with Cr(VI) ions, the broader bands such as N–H and O–H groups of chitosan or the kernel shell appeared at around 3300 cm−1 and 1040 cm−1 (skeletal vibration of C–O of chitosan or cellulosic structures of the kernel shell) was observed. The band appearing at 1728 cm−1 can be attributed to the carbonyl groups of kernel shell. This band was also observed in the spectrum of C-SCKS beads, but it did not appear in the spectrum of Cr(VI)-adsorbed C-SCKS beads. Following the adsorption of Cr(VI), the bands in the spectrum of C-SCKS were shifted to higher wavenumbers. Also, the presence of Cr(VI) ions led to a decrease in the absorption bands, suggesting adsorption of Cr(VI) by the adsorbent.

SEM analysis was used for the determination of surface morphology of R-SCKS, C-SCKS, R-SCKS-Cr(VI), and C-SCKS-Cr(VI). When looking at the SEM micrographs from Fig. 2, it was seen that after the adsorption of Cr(VI) for both adsorbents, the number of the particles on the surface increased and the gaps on the surface were filled. Compared to Fig. 2a and c, the rough structure of Fig. 2b and d was caused by the deposition of Cr(VI) during adsorption (Sari et al. 2017).
Fig. 2
Fig. 2

SEM micrograph of a sour cherry kernel shell powder (R-SCKS), b R-SCKS-(VI), c chitosan-coated sour cherry kernel shell powder beads (C-SCKS), and d C-SCKS-Cr(VI)

Besides, after the adsorption of Cr(VI) in both adsorbents, SEM-EDX analysis spectra (Fig. 3) were analyzed. In these spectra, the presence of the peaks of Cr(VI) was observed and in Fig. 3a and b, and Cr(VI) appears to be homogeneously distributed on the surface of the adsorbents. These results showed that Cr(VI) was kept on the surface for both adsorbents (Jiang et al. 2018). The uptake of Cr(VI) ions by the adsorbent was revealed by the EDX spectra (Fig. 3a, b). The affinity of chitosan for Cr(VI) ions can be seen from EDX spectra of Cr(VI)-loaded C-SCKS.
Fig. 3
Fig. 3

SEM-EDX spectra of a R-SCKS-Cr(VI) and b C-SCKS-Cr(VI)

Cr(VI) adsorption studies

Adsorbent dosage

Effect of adsorbent dosage on Cr(VI) adsorption was studied under the specified conditions: 25 °C, 61 mg/L of Cr(VI), pH 2.03, and contact time 120 min.

Adsorbent dosage for R-SCKS was studied between 0.02 and 0.204 g, while for C-SCKS was between 0.013 and 0.0802 g. The results were presented in Fig. 4. As seen from the figure, the critical adsorption dosage for C-SCKS was observed at around 0.05 g where the maximum Cr(VI) adsorption was recorded. The optimum amount was found to be 0.10 for R-SCKS. This amount was twice as much as that of C-SCKS, indicating the efficiency of C-SCKS.
Fig. 4
Fig. 4

Effect of the adsorbent dosage on Cr(VI) adsorption. R-SCKS sour cherry kernel shell powder, C-SCKS chitosan-coated sour cherry kernel shell powder beads

Cr(VI) concentration

The effect of concentration on Cr(VI) adsorption was tested at various concentrations of Cr(VI) ions: 12.7, 26.6, 60.8, 85.2, 115.2, 144.6, 170.5, 228.6, 314.0 ppm (25 °C, pH 2.03, adsorbent dosage 0.05 g (C-SCKS) and 0.1 g (R-CSKS), and contact time 120 min) (Fig. 5). Cr(VI) adsorption equilibrium data were evaluated by using Freundlich, Langmuir isotherm, the Scatchard plot analysis, and the Dubinin-Radushkevich (D-R) model (Edebali and Pehlivan 2016; Parlayici and Pehlivan 2017). The Freundlich isotherm constants are obtained by plotting log qe against log Ce using the linearized form of the model:
$$ \log\ {q}_{\mathrm{e}}=\log\ {K}_{\mathrm{F}}+\left(1/n\right)\ \log\ {C}_{\mathrm{e}} $$
(2)
where qe is the mass of metal ion sorbed by the sorbent (in mg g−1), Ce is the equilibrium metal ion concentration (in mmol L−1), and k (mmol g−1) and n are the Freundlich constants denoting the adsorption capacity and the intensity.
Fig. 5
Fig. 5

Effect of initial Cr(VI) ion concentration on adsorption of Cr(VI). R-SCKS sour cherry kernel shell powder, C-SCKS chitosan-coated sour cherry kernel shell powder beads

The Langmuir model is expressed in linear form as the following: the adsorption capacity As (in mmol g−1) and the energy of adsorption Kb (in L mmol−1) are calculated from the slope and intercept of the plot of Ce/qe vs. Ce:
$$ {C}_{\mathrm{e}}/{q}_{\mathrm{e}}={C}_{\mathrm{e}}/{A}_s+1/\left({A}_s{K}_{\mathrm{b}}\right) $$
(3)
where qe is the mass of metal ion adsorbed onto the sorbent (in mmol g−1) and Ce is the equilibrium concentration of metal ion (in mmol L−1).
The Scatchard plot analysis is expressed as follows:
$$ {q}_{\mathrm{e}}/{C}_{\mathrm{e}}={K}_{\mathrm{s}}\ \left({Q}_{\mathrm{s}}-{q}_{\mathrm{e}}\right) $$
(4)
where Ce is the equilibrium concentration of Cr(VI) in mmol L−1, qe is the equilibrium metal ion adsorption capacity in mmol L−1, and Ks (in L mmol−1) and Qs (in mmol g−1) are the Scatchard isotherm constants.
The D-R model:
$$ \ln X=\ln {X}_{\mathrm{m}}-{KE}^2 $$
(5)
where E (Polanyi potential) is [RT ln (1 + (1/Ce))], X and Xm in mmol g−1, and K in mol2 kJ−2.
The parameters and correlation coefficients obtained from the plots of Freundlich, Langmuir, Scatchard, and D-R are listed in Table 2.
Table 2

The parameters of Freundlich, Langmuir, Scatchard, and D-R isotherms for adsorption of Cr(VI) by sour cherry kernel shell powder (R-SCKS) and chitosan-coated sour cherry kernel shell powder beads (C-SCKS)

Cr6+ adsorbents

Freundlich isotherm

Langmuir isotherm

Scatchard isotherm

D–R isotherm

k

n

R 2

K b

A s

R 2

K s

Q s

R 2

X m

K

E

R 2

R-SCKS

1.457

2.12

0.959

260.4

0.261

0.993

394.98

0.232

0.932

0.416

0.0066

8.704

0.993

C-SCKS

1.265

3.153

0.996

255.8

0.471

0.960

117.68

0.545

0.915

2.049

0.0037

11.625

0.969

In the Scatchard plot analysis of Cr(VI) adsorption onto the adsorbents, the plot of qe/Ce against qe gave the straight line with high regression coefficients (R-SCKS, R2 0.932 and C-SCKS, R2 0.915), indicating that the adsorbent surfaces were homogenous and the metal ion sorption occurred through one type binding site (Akar et al. 2008). Also, based on the model assumptions, relatively high regression coefficients (R2 0.993) from the Langmuir model analysis demonstrated the homogeneity of the sorption sites on the adsorbent R-SCKS (Karimi et al. 2015, Pandey and Ramontja 2016).

Sorption system of Cr(VI) with C-SCKS was found to best fit to the Freundlich isotherm model with R2 0.996, indicating that the heterogeneity of the surface and the multilayer metal ion adsorption.

In the analysis of experimental data through D-R model, the value of E was found to be higher than 8 kJ mol−1 and lower than 16 kJ mol−1, demonstrating that the adsorption process by C-SCKS is supposed to proceed through ion exchange rather than physical interaction. In the case of R-SCKS, the value of E was about 8 kJ mol−1 and the adsorption by R-SCKS can be considered to be a physical mechanism (Tuzen and Sarı 2010).

Cr(VI) adsorption capacity of the R-SCKS and C-SCKS adsorbents and the literature reports were listed in Table 3. As seen from the table, R-SCKS and C-SCKS adsorbents had moderate Cr(VI) adsorption capacity. Especially, C-SCKS adsorbent can be used in Cr(VI) removal operations.
Table 3

Adsorption capacities of some adsorbents for Cr(VI) removal

Adsorbent

Maximum adsorption capacity (mg/g)

Literature

Rice husk carbon

8.80

(Ali 2010)

Natural bentonite

5.50

(Ali 2010)

Citric acid modified walnut shell

30.99

(Altun and Pehlivan 2012)

Modifying Turkish perlite with 훼-MnO2

7.60

(Edebali 2015)

Modifying Turkish perlite with 훾-Fe2O3

8.64

(Edebali 2015)

Fe3O4/Alginate-Ce3+ magnetic composite beads

14.29

(Gopalakannan and Viswanathan 2015)

Citric acid modification of peach kernel shell

25.71

(Parlayıcı 2018)

γ-Fe2O3 nanocrystals

12.50

(Tahar et al. 2018)

Magnetic magnetite (Fe3O4) nanoparticles

34.87

(Rajput et al. 2016)

Coconut charcoal

5.26

(Wu et al. 2013)

Bamboo charcoal grafted by Cu2+-N-aminopropylsilane complexes

17.94

(Wu et al. 2017)

Chitosan-coated sour cherry kernel shell beads (C-SCKS)

24.49

Present work

Sour cherry kernel shell powder (R-SCKS)

13.57

Present work

Effect of pH

Adsorption experiments were repeated for metal ion solutions with varying pH values (1.58, 2.03, 3.09, 3.94, 5.07, 5.99, and 6.95) (Cr(VI) ion concentration 61 mg g−1, temperature 25 °C, the mass of adsorbents 0.1 g (R-SCKS) and 0.05 g (C-SCKS), contact time 120 min). The effect of solution pH on the adsorption is depicted in Fig. 6. As presented in the figure, changes in Cr(VI) solution pH had a drastic effect on the adsorption process. Cr(VI) adsorption dropped sharply as the solution pH increased. A similar behavior was observed for R-SCKS and C-SCKS. The higher adsorption of Cr(VI) occurred under acidic conditions and at the lowest pH value yielded the maximum adsorption for both adsorbents. Cr(VI) occurs in aqueous solutions as anions in forms of CrO4−2, Cr2O7−2, and HCrO4 (Chen et al. 2010). It appears that the protonation of negatively charged functional moieties on the adsorbents enhanced Cr(VI) ions adsorption. On the other hand, lower adsorption at higher pH values can be ascribed to the electrostatic repulsion between Cr(VI) species and deprotonation of functional groups on the adsorbents and to the competition of Cr(VI) anions with OH. More efficient Cr(VI) adsorption by the adsorbent C-SCKS could have resulted from the protonated amino groups (–NH3+) groups of chitosan.
Fig. 6
Fig. 6

Effect of pH on Cr(VI) adsorption. R-SCKS sour cherry kernel shell powder, C-SCKS chitosan-coated sour cherry kernel shell powder beads

Thermodynamic analysis

To study the effect of temperature on Cr(VI) adsorption, equilibrium experiments were conducted at four different temperatures (298.15, 308.15, 323.15, and 338.15 K) (Cr(VI) ion concentration 61 mg L−1, pH 2.03, contact time 120 min, and adsorbent dosage 0.05 g for C-SCKS and 0.1 g for R-SCKS) (Fig. 7). Thermodynamics evaluation showed the feasibility of Cr(VI) sorption by the adsorbents at studied temperatures.
Fig. 7
Fig. 7

Effect of temperature on Cr(VI) adsorption. R-SCKS sour cherry kernel shell powder, C-SCKS chitosan-coated sour cherry kernel shell powder beads

The logarithm of the distribution coefficient values (KD) were plotted against temperature (1/T). By using the slope (∆H°/2.303R) and the intercept (∆H°/2.303R) of the plot and the van’t Hoff equation, changes in Gibbs free energy (∆G°), enthalpy (∆H°), and entropy (∆S°) were calculated (Table 4).
$$ \log {K}_{\mathrm{D}}=\left(\Delta {S}^{{}^{\circ}}/2.303\mathrm{R}\right)-\left(\Delta {H}^{{}^{\circ}}/2.303\mathrm{R}\mathrm{T}\right) $$
(6)
$$ \Delta {G}^{{}^{\circ}}=\kern0.5em \Delta {H}^{{}^{\circ}}-T\Delta {S}^{{}^{\circ}} $$
(7)
where R is universal gas constant (8.314 J mol−1 K−1) and T is the temperature (K).
Table 4

Thermodynamic parameters for the adsorption of Cr(VI) by sour cherry kernel shell powder (R-SCKS) and chitosan-coated sour cherry kernel shell powder beads (C-SCKS)

Cr(VI) adsorbents

ΔH° (J.mol−1)

ΔS° (J.K− 1 mol−1)

ΔG°(J.mol−1)

T = 298.15 K

T = 308.15 K

T = 323.15 K

T = 338.15 K

R-SCKS

0.01

14.00

− 4104.98

− 4315.02

− 4525.07

− 4735.11

C-SCKS

0.06

27.81

− 8153.21

− 8570.40

− 8987.59

− 9404.78

The sorption system of Cr(VI) by C-SCKS and R-SCKS showed a similar characteristic. The sorption of Cr(VI) by the adsorbents was exothermic in nature (negative ∆H°) and positive ∆S° exhibited that randomness in the systems increased. This increased randomness in the sorption system can be attributed to the transferring of the species with more energy from the sorption sites to the bulk phase following the adsorption of Cr(VI) ions onto the surfaces (Liu et al. 2011). ∆G° values were found to be negative for both adsorbent systems, showing that Cr(VI) sorption was spontaneous. The negative ∆G° for both sorption systems revealed that sorption of Cr(VI) by the adsorbents was favorable at the specified conditions.

Contact time

Contact time studies were done for 10, 15, 20, 30, 45, 50, 60, 90, 120, 180, and 240 min (temperature 25 °C, Cr(VI) ion concentration 61 mg L−1, pH 2.03, and adsorbent dosage 0.05 g for C-SCKS and 0.1 g for R-SCKS) (Fig. 8).
Fig. 8
Fig. 8

Effect of contact time on Cr(VI) adsorption. R-SCKS sour cherry kernel shell powder, C-SCKS chitosan-coated sour cherry kernel shell powder beads

In the Cr(VI)–C-SCKS system, the sorption was relatively faster and an equilibrium was reached in the first 50 min whereas an equilibrium was observed after 100 min for Cr(VI)-R-SCKS system. Longer contact time did not contribute much to the sorption capacity of both adsorbents. As a result, the optimum contact time was recorded as 45 min for the adsorbents C-SCKS and 90 min for R-SCKS.

Repeatability of the method

Cr(VI) sorption studies by C-SCKS and R-SCKS were repeated three times at the optimum conditions to test batch-to-batch variations (C-SCKS 25 °C, 61 mg/L Cr(VI) solution, pH 2.03, 0.05 g adsorbent amount, 45 min and R-SCKS 25 °C, 61 mg/L Cr(VI) solution, pH 2.03, 0.1 g adsorbent amount, 90 min). Adsorption percentage of C-SCKS was found as 85.63; 85.57, and 85.70% and adsorption percentage of R-SCKS were 82.50; 82.37, and 82.60%. The repeatability revealed that the method used in the study was reliable and batch-to-batch variations were negligible.

Desorption studies

Regeneration of the used adsorbents is an important part of the sorption studies. Using a regeneration procedure makes it possible to recover the adsorbed Cr(VI) ions from the solution and re-use of the adsorbent over. Regeneration also makes the adsorption process convenient and cheap. In the study, the regeneration experiments were done as follows: Cr(VI)-loaded R-SCKS or C-SCKS adsorbents were dried in an oven at 65 °C and then put into 1.0 M NaOH solution and shaken for 24 h. This procedure was repeated four times using the same adsorbent (Fig. 9). The desorption capacity of C-SCKS adsorbent was found to be higher (97.63%). The results showed that the adsorbent C-SCKS can be used in operations requiring reusability of the adsorbent.
Fig. 9
Fig. 9

Desorption efficiency after recycle use

Conclusions

This study reports an easy way for the production of biosorbent from the most abundant structural biopolymers in nature, cellulosic materials from plants and chitin from certain animals. The findings demonstrated that chitosan, a deacetylated derivative of chitin, was an excellent biopolymer for coating of powdered cellulosic materials from plants. Chitosan itself has an affinity for metal ions especially due to its hydroxyls and amino groups. It was observed that chitosan served as an immobilizing matrice for the powder of sour cherry kernel shells and enhanced their Cr(VI) adsorption capacity to some extent. Composite chitosan-coated kernel shell beads can be used as an effective biosorbent in the removal of Cr(VI) ions from acidic wastewater.

Abbreviations

C-SCKS:

Chitosan-coated sour cherry kernel shell powder beads

D-R:

Dubinin-Radushkevich

R-SCKS:

Raw sour cherry kernel shell

Declarations

Acknowledgements

Not Applicable

Funding

Not Applicable

Availability of data and materials

All data generated or analysed during this study are included in this published article.

Author’s contributions

TA is the only author of the manuscript. All studies, adsorption studies, characterization analysis, etc. mentioned in the article were performed by the author. The author read and approved the final manuscript.

Competing interests

The author declares that she has no competing interests.

Publisher’s Note

Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Open AccessThis article is distributed under the terms of the Creative Commons Attribution 4.0 International License (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted use, distribution, and reproduction in any medium, provided you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made.

Authors’ Affiliations

(1)
Department of Chemical Engineering, Faculty of Engineering, Selcuk University, Konya, Turkey
